Bosch Bosch vg5-7230-epc5 PTZ 2MP HDR 30x clear IP66 hoisting

Business type: vg5-7230-epc5







Product No.: f.01u three hundred and twenty-one point four two two
Vg5-7230-epc5 PTZ 2MP HDR 30x clear IP66 hoisting
Excellent performance under low illumination conditions
High dynamic range (120 dB) for challenging bright and dark scenes
Built in intelligent video analysis (IVA) for triggering related alerts and quickly retrieving data
The reliability of the camera is enhanced, and the optional dual redundant power supply ensures continuous all-weather operation
Dedicated AES 256 bit encryption engine for protecting recorded video
Imager 1 / 2.8 Exmor r CMOS sensor
Effective primitives (pixels) 1945 x 1097 (2.13 MP)
Lens 30x electric zoom 4.3mm to 129mm F1 6 to F4 seven
FOV 2.3 ° to 63.7 °
Focusing is automatic and can be controlled manually
The aperture is automatic and can be controlled manually
Digital zoom 12x
Video performance - sensitivity
(3100K, reflectivity 89%, 1 / 30, f1.6, 30 IRE)
Color 0.0077 LX
Black and white 0.0008 LX
Gain control AGC, fixed
Aperture distortion correction horizontal and vertical
Electronic shutter speed (AES) 1 / 1 second to 1 / 10000 second (level 22)
Signal to noise ratio (SNR) > 55 dB
Day / night switching automatic infrared filter
Backlight compensation (BLC) on / off / intelligent automatic exposure (IAE)
White balance 2000 K to 10000 K ATW, AWB hold, extended ATW, manual, sodium lamp auto, sodium lamp
Day / night, black and white, color, automatic
The anti fog mode function improves visibility when viewing foggy or other low contrast scenes.
Horizontal rotation range 360 ° continuous
Pitch angle 18 ° above horizontal
Preset speed horizontal rotation: 400 ° / s pitch: 300 ° / S
Horizontal rotation / pitch mode
Turbine mode (manual control) horizontal rotation: 0.1 ° / s – 400 ° / s pitch: 0.1 ° / s – 300 ° / S
Normal mode 0.1 ° / S - 120 ° / S
Preset position accuracy ± 0.1 ° (typical)
Input voltage 21-30 VAC, 50 / 60 Hz; (class II) high power POE (with Bosch midspan (npd-6001a); Devices necessary to power heaters) Poe + (IEEE 802.3at, class 4 standard) (do not power heaters when used indoors)
Power consumption (typical) 60 W / 69 VA (heater on) or 24 w / 44 VA (heater off / heater not connected in the power box in indoor applications)
Alarm input protection peak current 17 A, peak power 300 W (8 / 20 μ s)
Alarm output protection peak current 2 A, peak power 300 W (8 / 20 μ s)
Relay output protection peak current 7.3 a, peak power 600 W (10 / 1000 μ s)
Power input protection (spherical camera) peak current 7.3 a, peak power 600 W (10 / 1000) μ s)
Power output protection (boom power supply) peak current 21.4 a, peak power 1500 W (10 / 1000) μ s)
10 / 100 Ethernet data line peak current 14 A, peak power 200 W (8 / 20) μ s)
Camera setup / control via web browser (e.g. Internet Explorer version 7.0 or later), Bosch configuration manager, Bosch video management system (BVMs), Bosch recording station (BRS), or Bosch video client (BVC)
Software update network firmware upload
Serial protocols Bosch OSRD, PELCO P / D and forward vision (Note: for PELCO and forward vision protocols, a separate license (mvs-fcom-prcl) is required.)
Standard / video compression H.264 (ISO / IEC 14496 ? 10), m ? JPEG, JPEG
Data stream four (4) data streams with separately configurable frame rate and definition: two (2) separately configurable H.264 vieo streams and two (2) non video streams (Profiles)
When the following options are available in the dataflow field: 1:
H.264 MP SD - H.264 MP SD
H. 264 MP 720p fixed - H.264 MP SD - H.264 MP 720p fixed - H.264 MP 400x720 upright (cut) - H.264 MP D1 4:3 (cut) - H.264 MP 1280x960 (cut) - H.264 MP 640x480

H. 264 MP 1080p fixed - copy data stream 1 - H.264 MP SD - H.264 MP 720p8 / 10 fixed - H.264 MP 1080p4 / 5 fixed - H.264 MP 400x720 upright (crop) - H.264 MP D1 4:3 (crop) - H.264 MP 640x480

H. 264 MP 720p50 / 60 fixed - copy data stream 1 - H.264 MP SD - H.264 MP 720p6 / 7 fixed - H.264 MP 400x720 upright (crop) - H.264 MP D1 4:3 (crop) - H.264 MP 640x480

There are two (2) data streams in the non recording profile, only I-frame options include: - optimize HD image - balance HD image - optimize HD bit rate - optimize SD image - balance SD image - optimize SD bit rate - optimize DSL - optimize 3G

Resolution (horizontal x vertical)

1080p HD 1920 x 1080 (16:9)

720p HD 1280 x 720

432p SD 768 x 432

288p SD 512 x 288

144p SD 256 x 144

Protocols IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP / RTCP, IGMP V2 / V3, ICMP, ICMPv6, RTSP, FTP, Telnet, ARP, DHCP, APIPA (auto IP, link local address), NTP (SNTP), 802.1x, DNS, dnsv6, DDNS (dyn.com, selfhost.de, no IP. Com), SMTP, iSCSI, UPnP (SSDP), DiffServ (QoS), lldp, soap, Dropbox ?、 CHAP、digest authentication

Ethernet 10Base-T / 100base-tx, automatic detection, half / full duplex

Encryption TLS 1.0, SSL, DES, 3DES, AES

Ethernet connector RJ45

Connect onvif profile s, auto mdix

GOP structure IP, IBP, ibbp

Data transmission rate 9.6 Kbps to 6 Mbps

Overall IP delay 120 ms (60 FPS mode)

audio frequency

-Standard G.711, 8 kHz sampling rate L16, 16 kHz sampling rate AAC, 16 kHz sampling rate

-SNR > 50 dB

-Audio stream bidirectional (full duplex)

Memory card socket SD / SDHC / SDXC memory card provided by the user (up to 2TB – SDXC)

Video recording, continuous recording of video and audio, alarm / event / schedule recording

VG4-SFPSCKT

6. Optical Ethernet media converter kit description Requires small form factor pluggable (SFP) modules (sold separately).

Data interface Ethernet

The data transmission rate is 10 / 100 Mbps, which complies with IEEE 802.3 standard, full duplex or half duplex electrical port, full duplex optical fiber port

Compatible receiver cnfe2mc

The installation hardware provided is installed in the vg4-a-pa0, vg4-a-pa1, vg4-a-pa2, vg4 ? a ? psu1 or vg4 ? a ? psu2 power box

6. The kit needs to be purchased independently and must be installed in the autodome power box.

Describe interchangeable modules that can be used with MMF or SMF optical fibers.

Data interface Ethernet

The data transmission rate is 10 / 100 Mbps, which complies with IEEE 802.3 standard

Weight (all SFP modules) 0.23 kg (0.05 lb)

Dimensions (L x W x H) sfp-2, sfp-3: 55.5mm x 13.5mm x 8.5mm (2.2in x 0.5in x 0.3in) sfp-25, sfp-26: 63.8mm x 13.5mm x 8.5mm (2.5in x 0.5in x 0.3in)

Type connector, wavelength (transmit / receive), maximum distance

Sfp-2 MMF, duplex LC, 1310 nm / 1310 nm, 2 km (1.2 miles)

Sfp-3 SMF, duplex LC, 1310 nm / 1310 nm, 20 km (12.4 miles)

Sfp-25 MMF, single SC, 1310 nm / 1550 nm, 2 km (1.2 miles)

Sfp-26 MMF, single SC, 1550 nm / 1310 nm, 2 km (1.2 miles)

Optical fiber compatibility

Fiber compatibility, MMF 50 / 125 micron MMF. For 50 / 125 micron fibers, subtract 4 dB from the specified optical budget. Must meet or exceed the optical fiber standard ITU-T g.651.

Fiber compatibility, SMF 8 – 10 / 125 micron SMF. Must meet or exceed the optical fiber standard ITU-T G.652.

The transmission distance specified in the optical distance specification is limited by the optical loss of the optical fiber and any other loss caused by connectors, wires and plug-in panels. These modules are specially designed to operate within the entire optical loss budget, so there is no need to specify a minimum loss.

Sector / Title 16 independent sectors, each sector can be set with a title of 20 characters

Mask 24 individually configurable privacy masks

There are 256 preset bits, and 20 character titles can be set at each position

Two (2) types of tour routes: recorded tour routes – two (2) preset tour routes – one (1), including up to 256 consecutive scenes

The supported languages are English, Chinese, Dutch, French, German, Italian, Japanese, polish, Portuguese and Spanish

Camera power RJ-45 10 / 100 base TX Ethernet (high power Ethernet power supply (high power POE)) or Poe + (IEEE 802.3at, class 4 standard) 21-30 VAC, 50 / 60 Hz

Heater power supply RJ-45 10 / 100 base TX Ethernet (high power Ethernet power supply (high power POE)) 21-30 VAC, 50 / 60 Hz

Video and control RJ-45 10 / 100 base TX Ethernet

Two alarm inputs (7) are monitored and five are not monitored. They can be programmed for "normally open" or "normally closed"

Alarm output (4) 1 dry contact relay, 3 open collector / transistor outputs 32 VDC @ 150 mA Max

Audio 1 channel mono line input, 1 channel mono line output

Signal line input 12 kiloohms (typ.), 1 VRMs (max.)

Signal line output 1 VRMs, 1.5k Ω (typ.)

Waterproof and dustproof grade / standard IP66, NEMA 4x

Operating temperature (heater connected) - 34 to + 74 ° C (- 30 to + 165 ° f) (in accordance with NEMA TS 2-2003 (R2008), section 2.1.5.1) - 40 to + 55 ° C (- 40 to + 131 ° f) (continuous operation)

Operating temperature (heater not connected) - 10 to + 55 ° C (+ 14 to + 131 ° f) (continuous operation)

Storage temperature - 40 to + 60 ° C (- 40 to + 140 ° f)

Operating humidity 0% to 100% relative humidity, condensation 7

Size 224 mm x 299 mm (8.8 in X 11.8 in) (with sunshade)

Weight 3.07 kg (6.77 lb)

Ball cap size 153.1 mm diameter (6.03 in)

Structural materials

Protective cover cast aluminum

Spherical cover high definition acrylic plexiglass

Standard color white (RAL 9003)

Standard coating, powder coating, powder painting

Description part number

High definition acrylic plexiglass transparent spherical cover vga-bubble-pcla

High definition acrylic plexiglass colored ball cover vga-bubble-ptia

Durable and ik10 compliant polyamide fiber transparent ball cover vga-bubble-ik10

Lifting arm base

Hanging arm (without transformer) vg4-a-pa0

Hanging arm (120 / 230 VAC transformer) vg4-a-pa1 / vg4-a-pa2

Vga-pend-arm with cable

VGA-PEND-A
