Sony snc-hm662 5 megapixel 360 degree hemispherical view camera






Product overview:

Capture a clear, delicate and uninterrupted 360 degree view with a 5 megapixel CMOS imager

Snc-hm662 IP webcam provides uninterrupted 360 degree hemispherical field of view. It is an ideal "overview camera" solution that can be used to closely monitor a wide range of indoor and outdoor environments - from halls, waiting rooms and retail spaces to parking lots, campuses and commercial buildings.

Although ordinary fisheye lenses are often used for 360 degree wide-angle coverage, the image quality at the edge of the image is seriously degraded. Snc-hm662 adopts a completely different method. It uses the unique panomorph lens of immervision to take a real hemispherical view without any blind spots. The video clip captured by the 5 megapixel imager has a frame rate of up to 13 FPS, and the picture edge can also be kept clear and detailed.

The resulting 360 degree image can be automatically "restored" to provide a clear and distortion free view through Sony web browser client or VMS (video management software) client application. Electronic pan / pitch / Zoom (eptz) supports fast navigation to any part of the camera's field of view for close observation.

Client applications provide multiple view modes. It includes the original 360 degree hemispherical view of the camera and multiple synchronous views generated from the same hemispherical image (including 180 degree panoramic view, four view and 9-way split screen view).

Even when the client watches a part of the scene in close range, the camera can continue to stream the whole image to this recording platform. After recording, you can recheck the clip of the whole area. The operator can also play the clip flexibly, just like viewing in real time, so as to zoom in on any part of the 360 degree scene for careful viewing.

Other improvements provided by snc-hm662 include recording two-way audio through a built-in microphone. Power over Ethernet (POE) helps simplify installation, while edge storage supports "no network" recording to removable memory cards. Snc-hm662 can operate in a wide temperature range from - 30 ° C to + 50 ° C. It also has IP66 and ik10 waterproof and impact resistance grades, which makes it especially suitable for outdoor applications.



Sony Sony 5 megapixel 360 degree hemispherical view camera snc-hm662 main parameters:

video camera

Imager 1 / 2.5 inch progressive CMOS imager

Effective resolution About 5 million pixels

Minimum illumination (50 IRE) Color: 0.7 LX (f2.0, AGC on, 1 / 30 s, 10 FPS)

Black and white: 0.3 LX (f2.0, AGC on, 1 / 30 s, 10 FPS)

Minimum illumination (30 IRE) Color: 0.4 LX (f2.0, AGC on, 1 / 30 s, 10 FPS)

Black and white: 0.1 LX (f2.0, AGC on, 1 / 30 s, 10 FPS)

Signal to noise ratio (0 dB gain) Greater than 60 dB

gain automatic

shutter speed 1 / 5 s to 1 / 32000 s

Exposure control Exposure compensation, shutter speed

white balance Automatic tracking white balance, manual

camera lens Fixed lens

Zoom magnification 12x digital zoom

12x total zoom

Horizontal perspective 182°

Vertical viewing angle 182°

focusing F = 0.98 mm to 1.12 mm

F value F2. 0

Shortest object distance 500 mm

Number of preset bits twenty

Number of panoramic projects one

Camera function

Day night conversion Mechanical day night conversion

360 ° hemispherical view / 180 ° panoramic view mode Yes / Yes (total view modes: 11) * 1

Automatic rotation mode yes

Flip vertically yes

Wide dynamic range yes

Tone correction Global tone mapping

Privacy occlusion (digital) five

Privacy occlusion (shape) A quadrilateral formed by any four corners

Privacy occlusion (color / effect) Opaque 1 color (black)

Edge storage yes

Anti damage level IK10

Degree of protection IP66

Superimposed language English

Menu language English, Japanese, simplified Chinese, traditional Chinese, French, Spanish, German, Italian, Korean, Portuguese, Russian, Arabic, Hindi, Vietnamese, Thai

video

resolving power 2560 x 19202048 x 15361600 x 1200800 x 600640 x 480 (fisheye mode: H.264, JPEG)

1920 x 1080, 1600 x 904, 1360 x 768, 1280 x 720, 640 x 360 (1080p mode: H.264, JPEG)

Compression format H. 264 (advanced class / main class / baseline class), JPEG

Maximum frame rate H.264： 10 fps (2560 x 1920)/30 fps (1920 x 1080)

JPEG： 13 fps (2560 x 1920)/30 fps (1920 x 1080)

Bit rate control mode CBR / VBR (optional)

Bit rate setting range 20 Kbps to 16 Mbps

Image clipping 1920 x 1080

Solid state PTZ yes

Adaptive rate control H.264

Bandwidth control JPEG

Multi stream function Yes (3)

Number of clients ten

Intelligent video / audio analysis

Intelligent mobile detection yes

Anti damage detection yes

audio frequency

Compression format G.711/AAC（32 kHz、44.1 kHz）

system requirements

operating system Windows XP (32 bit) professional

Windows Vista (32 bit) ultimate, business

Windows 7 (32 / 64 bit) ultimate, professional

Windows 8 Pro (32/64 bit)

processor Intel core7 2.8GhZ or higher

Memory 2 GB or higher

Web browser Microsoft Internet Explorer version 8.0, version 9.0, version 10.0 (32-bit)

SNC toolbox yes

network

agreement IPv4、TCP、UDP、ARP、ICMP、IGMP、HTTP、DHCP、DNS、NTP、RTP/RTCP、RTSP over TCP、RTSP over HTTP、SMTP、IPv6、HTTPS、SNMP（v1、v2c、v3）、SSL

IP address number / MAC address one

QoS DSCP

Multicast streaming support yes

Comply with onvif standard Profile S

Authentication IEEE802. 1X

Interface

Microphone input Built in microphone / external microphone input

Line input Mini jack (mono)

Line output Mini jack (mono), maximum output level: 1Vrms

Network port 10BASE-T/100BASE-TX (RJ-45)

Alarm input (imager input) X1, close contact, open contact

Alarm output X1, 24V DC, 0.5A (electrical switch output. Isolated by optocoupler)

Card slot micro SD x1

Confirmed SD card type MicroSDHC (microsdxc not supported)

general information

Power requirements Comply with IEEE 802.3af (POE system), DC 12V ± 10%

power waste 6.0 w Max

working temperature - 30 ° C to + 50 ° C

-22 ° f to + 122 ° f

Cold start temperature - 20 ° C to + 50 ° C

-4 ° f to + 122 ° f

Storage temperature - 25 ° C to + 60 ° C

-13 ° f to + 140 ° f

Working humidity 20% to 90%

Storage humidity 20% to 95%

Size * 2 Φ 145 mm x 54 mm (without mounting plate)

Φ 5 3 / 4 x 2 1 / 4 inch (without mounting plate)

Φ 147 mm x 70 mm (including mounting plate)

Φ 5 7 / 8 x 2 7 / 8 inches (including mounting plate)

weight Approx. 640 g (without mounting plate)

Approx. 1 lb 7 oz (without mounting plate)

About 716 g (including mounting plate)

Approx. 1 lb 9 oz (including mounting plate)

External materials Transparent ball cover: PC

Top cover: cast aluminum

Top cover ring: PC

Camera base: cast aluminum

Mounting plate: cast aluminum

Exterior color Top cover: Black

Top cover ring: white

Camera base: white

Mounting plate: white

Flame retardant UL94HB

Safety rules Jate technical standard (LAN)

UL2044，IEC60950-1（CB)

VCCI class B, FCC class B, IC class B,

Electromagnetic radiation: en55022 (class B) + en50130-4

Anti interference: en55022 (class B) + en55024,

Electromagnetic radiation: as / NZS cispr22 (class B)

KCC

EAC (GOST-R)

Standard accessories Installation disk (1)

I / O cable (1)

Camera base positioning sticker (1)

Mounting plate positioning sticker (1)

Screwdriver (1)

Desiccant (1)

Double sided adhesive tape (1)

Rubber sealing plug (1)

Rubber washer (1)

Screw (for mounting plate) (1)

Installation manual (1)

Warranty card (1)

Webcam security rules (1)

CD-ROM (provider) (1)

Optional Accessories Uni-mdphm (hemispherical ball machine pendant connection shield)
