Sony snc-vb600b5 1.3 megapixel color to black color to black gun machine


Sony Exmor CMOS imager can capture clear and low-noise HD images, and can implement reliable monitoring even under dark light conditions.

As one of Sony's latest generation video security cameras, snc-vb600b5 adopts Sony's award-winning ipela engine ex processing platform. This improves image quality in a variety of environments, including challenging low light conditions.

View Dr technology LT expands the dynamic range and improves the imaging quality under high contrast and strong backlight conditions such as bright office or parking lot entrance. The image stabilization function also helps to keep the video image clear and bright, even when the camera vibrates on the mounting column or support.

Sony 1.3 megapixel color to black color to black gun snc-vb600b5 main features:

1 / 3 inch progressive Exmor CMOS

Sony's Exmor CMOS, with its high speed, high sensitivity and high image quality, has been successfully applied to various fields including surveillance cameras.

1.3 megapixel HD, high quality, real-time image

It can provide (720p / 30 frames) real-time images.

H. 264 (high / main / baseline profile) / JPEG encoding format

Three bit stream function

It supports three code streams of the same and different arbitrary formats, which provides great flexibility for various applications.

Bit rate mode optional

VBR (variable bit rate) and CBR (constant bit rate) coding modes are available to suit different network applications.

Wide dynamic technology (view Dr LT)

Sony's view Dr LT technology has excellent wide dynamic performance and can provide high-quality images even in low light or strong light dark contrast scenes.

Visibility Enhancement Technology (VE)

It can effectively optimize the image contrast and make the monitoring picture have better visual performance. It is very suitable for scenes where the monitoring target is difficult to distinguish, such as severe backlight or shadow.

Super dynamic noise reduction function (xdnr)

Super dynamic noise reduction technology ensures that the edge of moving objects in low illumination environment is clear without trailing.

Day night electronic conversion function

Electronic day night conversion function, which can automatically switch color or black-and-white mode according to the light changes in the monitoring environment.

Depa advanced intelligent analysis

Depa advanced intelligent function, which triggers alarms based on user-defined rules.

Smart phone terminal

The camera can be accessed via a smartphone.

Support Poe network power supply

Only one network cable is needed to connect the camera to realize the transmission of video, audio and alarm information, as well as the control and power supply of the equipment, which greatly saves the installation cost and facilitates the process of installation and debugging.

Image anti shake function

It can effectively reduce the impact of slight camera jitter caused by the external environment on the image definition.

Comply with onvif profile s standard

Onvif (open network video interface Forum) standard ensures the interoperability of network video products produced by different manufacturers.

Sony 1.3 megapixel color to black color to black gun snc-eb600b detailed technical parameters:



SNC-VB600B




Imager 1 / 3 inch progressive Exmor CMOS

Number of effective pixels About 13700 pixels

signalling system NTSC / PAL (switchable)

synchronous system Internal synchronization

Minimum illumination (50 IRE) Color: 0.05 LX (f1.0, view Dr off, ve off, AGC on, 1 / 30 s, 30 FPS)

Black / White: 0.04 LX (f1.0, view Dr off, ve off, AGC on, 1 / 30 s, 30 FPS)

Minimum illumination (30 IRE) Color: 0.03 LX (f1.0, view Dr off, ve off, AGC on, 1 / 30 s, 30 FPS)

Black / White: 0.02 LX (f1.0, view Dr off, ve off, AGC on, 1 / 30 s, 30 FPS)

dynamic range Equivalent to 90 dB through view Dr LT Technology

Signal to noise ratio (0 dB gain) Greater than 50 dB

gain automatic

shutter speed 1 / 1 second to 1 / 10000 second

Exposure control Exposure compensation, automatic gain control, shutter speed, aperture

white balance ATW, atw-pro, fluorescent lamp, mercury lamp, sodium vapor lamp, metal halogen lamp, white LED, one touch white balance, manual

camera lens CS interface zoom lens

Powerful zoom no

Simple zoom no

Zoom magnification 2.7x optical zoom

4X digital zoom

10.8x total zoom

Electric focusing no

Auto focus no

Simple focusing and convenient setting no

Horizontal perspective 92.5 ° to 35.7 °

Vertical viewing angle 72.7 ° to 28.6 °

focal length F = 3.0 mm to 8.0 mm

F value F1. 0 (wide angle) to F1 65 (telephoto)

Shortest object distance 200 mm

Number of preset bits no

Number of panoramic projects no

IR lamp no

IR working distance no

White LED lighting no

Led working distance no

Camera function

Day night conversion Electronic day night conversion

Day / night mode is associated with simple focusing no

Flip vertically no

Wide dynamic range View-DR LT

Tone correction Enhanced visibility (VE)

Defogging image processing no

noise reduction XDNR

Image stabilizer yes

Image mode yes

Privacy occlusion (digital) twenty

Privacy occlusion (shape) A quadrilateral formed by any four corners

Privacy occlusion (color / effect) Opaque: 14 colors (black, white, red, green, blue, cyan, yellow, magenta, gray (Level 6)), mosaic

Edge storage no

Image memory no

Size of image memory no

Pre buffer / post buffer memory size no

Compatible cloud services no

Voice alarm no

Anti damage level no

Degree of protection no

Digital superposition 3 independent character positions (codec, date and time, event, text (up to 64 characters)), 1 independent logo marking position

Superimposed language English

Menu language English, Japanese, simplified Chinese, traditional Chinese, French, Spanish, German, Italian, Korean, Portuguese, Russian, Arabic, Hindi, Vietnamese, Thai

Smartphone viewer yes

video

resolving power 1280 * 1024，1280 * 960，1024 x 768，1280 * 720，800 * 600，720 * 576，720 * 480，704 x 576，640 * 480，352 x 288，320 * 240（H.264，JPEG）

Compression format H. 264 (advanced class / main class / baseline class), JPEG

Maximum frame rate H.264： 30 fps (1280 * 1024)

JPEG： 30 fps (1280 * 1024)

Bit rate compression mode CBR / VBR (optional)

Bit rate setting range 64 Kbps to 32 kbps

Image clipping no

Solid state PTZ yes

Adaptive rate control H.264

Bandwidth control JPEG

Multi stream function Three bit rate

Number of clients twenty

mailbox no

Intelligent video / audio analysis

analytical framework Depa advanced intelligent

Intelligent mobile detection yes

Face detection yes

Anti damage detection yes

Advanced audio detection no

Scene analysis Through, intrusion, abandoned object detection, removed object detection

automatic tracking no

system requirements

operating system Windows XP (32 bit) professional

Windows Vista (32 bit) ultimate, business

Windows 7 (32 / 64 bit) ultimate, professional

Windows 8 Pro (32/64 bit)

Windows 8.1 Pro (32/64 bit)

processor Intel Core i7 2.8 GHz or higher

Memory 2 GB or higher

Web browser Microsoft Internet Explorer version 7.0 version 8.0 version 9.0 version 10.0 version 11.0

Firefox version 19.02 (for viewfinder without plug-in only)

Safari version 5.1 (for viewfinder without plug-in only)

Google Chrome version 25.0 (only applicable to viewfinder without plug-in)

network

agreement Support IPv4, TCP, UDP, ARP, ICMP, IGMP *, HTTP, DHCP, DNS, NTP, RTP / RTCP, RTSP over TCP, SMTP over HTTP, IPv6, HTTPS, FTP (client only), SNMP (V1, V2C, V3), SSL * SSM (source specific multicast).

IP address number / MAC address one

QoS DSCP

Multicast streaming support yes

Comply with onvif standard Profile S

wireless network no

Wi Fi authentication no

Wi Fi protection settings (WPS) no

Authentication IEEE 802.1X

Interface

Analog video input no

Analog video output no

Analog monitor output (for setup) Mini jack x1

Analog video output / SLOC port no

SLOC port no

Composite buffer output no

Microphone input no

Line input no

Line output no

Network port 10BASE-T/100BASE-TX (RJ-45)

Alarm input (imager input) no

Alarm output no

Alarm output no

serial interface no

Card slot no

Confirmed SD card type no

USB slot no

general information

Power requirements IEEE 802.3af compliant (POE system)

power waste 5.0 w Max

working temperature - 10 ℃ to + 50 ℃

14 ° f to 122 ° f

Cold start temperature 0 ℃ to + 50 ℃

32 ° f to 122 ° f

Storage temperature - 20 ℃ to + 60 ℃

-4°F - +140°F

Working humidity 20% to 80%

Storage humidity 20% to 95%

Built in heater no

Size * 1 72 x 63 x 145 mm (without lens)

2 7 / 8 x 2 1 / 2 x 5 3 / 4 inches (without lens)

72 mm x 63 mm x188 mm (including lens)

5 7 / 8 x 2 1 / 2 x 7 1 / 2 inches (with lens)

weight About 460 g (including lens)

Approximately 1 lb 0.2 oz

External materials Top cover: secc-cf

Bottom cover: secc-cf

Front panel: ADC12

Rear panel: PC + ABS

Exterior color Top cover: Munsell 3.6gy 8.4 / 0.3

Bottom cover: Munsell 3.6gy 8.4/0.3

Front panel: Munsell 3.5pb 2.2/0.4

Rear panel: Munsell 4.4bg 8.4 / 0.2

Flame retardant UL2044

Safety rules Jate technical standard (LAN)

UL2044，IEC60950-1 (CB)

VCCI (Class A), FCC (Class A), IC (Class A)

Electromagnetic radiation: en55022 (Class A) + en50130-4

Anti interference: en55022 (Class A) + en55024

Electromagnetic radiation: as / NZS cispr22 (Class A)

KCC

EMC-TR
